4 Ohm High Power Sub Drivers
18" sub 4ohm 600W
902.128UK
SUBCASA-18BA
High power handling 4 Ohm low frequency drivers with large diameter voice coil and reinforced cone. Designed for installing into ported or folded cabinets to add high energy sub frequencies and… more
- Direct replacements for CASA series active sub cabinets
4 Ohm High Power Sub Drivers
High power handling 4 Ohm low frequency drivers with large diameter voice coil and reinforced cone. Designed for installing into ported or folded cabinets to add high energy sub frequencies and explosive dynamics in medium to large PA systems.
- Direct replacements for CASA series active sub cabinets
- Weight 9.2kg
- Dimensions 230 x 462mmØ
- Sensitivity 97dB
- Magnet 190 x 90 x 20mm (80oz)
- Voice coil 76mmØ (3")
- Frequency response 45Hz - 3kHz
- Power handling : max 1100W
- Power handling : rms 600W
- Construction Reinforced paper cone with steel frame basket
- Impedance 4 Ohms
In the Box
- 4 Ohm high power sub woofer driver
