4 Ohm High Power Sub Drivers
12" sub 4ohm 400Wrms
902.122UK
SUBCASA-12BA
High power handling 4 Ohm low frequency drivers with large diameter voice coil and reinforced cone. Designed for installing into ported or folded cabinets to add high energy sub frequencies and… more
- Direct replacements for CASA series active sub cabinets
4 Ohm High Power Sub Drivers
High power handling 4 Ohm low frequency drivers with large diameter voice coil and reinforced cone. Designed for installing into ported or folded cabinets to add high energy sub frequencies and explosive dynamics in medium to large PA systems.
- Direct replacements for CASA series active sub cabinets
- Weight 4.8kg
- Dimensions 160 x 310mmØ
- Sensitivity 96dB
- Magnet 156 x 80 x 20mm (50oz)
- Voice coil 64mmØ (2.5")
- Frequency response 45Hz - 2kHz
- Power handling : max 700W
- Power handling : rms 400W
- Construction Reinforced paper cone with steel frame basket
- Impedance 4 Ohms
In the Box
- 4 Ohm high power sub woofer driver
