RMC-series Mixer-Amps 100V with CD, DAB+, BT and mp3 Player

120W

953.142UK
RMC120D

100V line mixer-amplifiers with built-in multi-format media player. 5 input channels include a balanced XLR microphone input with switchable phantom power and Vox override, 2 mic/line jack inputs and… more

  • 5 input channels
  • DAB+ and FM radio tuner
  • Slot feed CD player
DESCRIPTION OUTPUT POWER PACKED
953.142UK

RMC120D Mixer-amp 204W + CD/BT/USB/SD/DAB/FM

120W Box Label

RMC-series Mixer-Amps 100V with CD, DAB+, BT and mp3 Player

100V line mixer-amplifiers with built-in multi-format media player. 5 input channels include a balanced XLR microphone input with switchable phantom power and Vox override, 2 mic/line jack inputs and 2 RCA line inputs. A powerful class AB amplifier section is paired with a digital switch-mode power supply and 100V transformer for reliable power delivery from an energy efficient power section. A built-in CD player provides audio playback alongside a USB/SD media player with an integral DAB+ and FM radio tuner. A Bluetooth® receiver enables pairing to a smartphone for wireless playback of stored tracks. Bass & Treble EQ and Master volume control the overall output, which can power either low impedance or 100V line speakers. A comprehensive solution for commercial sound installations.

  • 5 input channels
  • DAB+ and FM radio tuner
  • Slot feed CD player
  • Bluetooth connectivity
  • USB/SD mp3 player
  • 100V or 4-16 Ohms output
  • Supplied with 19" rack-mount ears
  • Optional remote control available SPR000708
  • Power supply 170-264Vac, 50Hz (IEC)
  • Fuse T3.15A
  • DC power 24Vdc (screw terminals)
  • Power : rms 120Wrms (100V or 4 Ohms)
  • Inputs Mic XLR, 2 x mic/line jack, 2 x RCA line
  • Input sensitivity : mic 1 (balanced) -53dBV
  • Input impedance : mic 1 5k Ohms
  • Input sensitivity : line (unbalanced) -15dBV (-18.5dBV line 5)
  • Input impedance : inputs 2-5 1k Ohms
  • Line output RCA
  • Speaker outputs 100V / 4-16 Ohms / COM terminals
  • Bluetooth version 5.0
  • Controls Mic1, mic/line2+3, line4+5 (USB), bass, treble, master volume
  • Equaliser : bass 100Hz ±10dB
  • Equaliser : treble 10kHz ±10dB
  • Rear panel switches Mic/Line (2 + 3), Phantom, Vox
  • Phantom power +20V (MIC 1 input)
  • THD <1.0%
  • Dimensions 433 x 320 x 89mm
  • Weight 7kg
