30m 24V IP66 Dome Frosted LED Tape
30m of unique LED tape that is 10mm wide and features a domed frosted extrusion surface to give a seamless smooth look without the need for a profile. Available in Warm White, Natural White and Cool… more
- Silicone integrated extrusion technology
- 30m reel - cut to length
- Seamless design
| DESCRIPTION | VERSION | PACKED | ||
|---|---|---|---|---|
|
156.745UK
24V IP66 Dome Frosted WW 30m |
Box Label | ||
|
156.746UK
24V IP66 Dome Frosted NW 30m |
Box Label | ||
|
156.747UK
24V IP66 Dome Frosted CW 30m |
Box Label | ||
Recommended Accessories |
||||
|
153.627UK
RTV Silicone glue |
Gift Box | ||
|
153.759UK
Power Supply 24Vdc 2.50A 60W |
24Vdc 2.50A 60W | Box Label | |
|
153.760UK
Power Supply 24Vdc 4.16A 100W |
24Vdc 4.16A 100W | Box Label | |
|
153.761UK
Power Supply 24Vdc 6.25A 150W |
24Vdc 6.25A 150W | Box Label | |
|
153.762UK
Power Supply 24Vdc 8.33A 200W |
24Vdc 8.33A 200W | Box Label | |
|
153.763UK
Power Supply 24Vdc 10.4A 250W |
24Vdc 10.4A 250W | Box Label | |
|
153.764UK
Power Supply 24Vdc 12.5A 300W |
24Vdc 12.5A 300W | Box Label | |
|
156.162UK
10mm Dome End Cap 5pk |
Poly Bag | ||
|
156.163UK
10mm Dome End Cap Cable 5pk |
Poly Bag | ||
|
156.164UK
10mm Dome clips & screws 5pk |
Poly Bag | ||
|
156.643UK
8mm to DC 2.1mm F Crimp (5pk) |
8mm | Poly Bag | |
|
156.646UK
9-Way 8mm Transparent COB Connector (5pk) |
8mm 9-way | Poly Bag | |
|
156.659UK
Single Colour COB Flexible Link - 5 Pack |
1-Colour 8mm | Poly Bag | |
30m 24V IP66 Dome Frosted LED Tape
30m of unique LED tape that is 10mm wide and features a domed frosted extrusion surface to give a seamless smooth look without the need for a profile. Available in Warm White, Natural White and Cool White, this IP66 rated tape has multiple applications in home and commercial applications.
- Silicone integrated extrusion technology
- 30m reel - cut to length
- Seamless design
- Recommended max. run length 10m with a single power supply
- Installation accessories available separately
- Adhesive backing
- Colour temperature 4000K
- Lumens 792 lm/m
- Tape version 8mm COB
- Colour temperature WW 2700K, NW 4000K, CW 5000K
- Colour Warm White, Natural White or Cool White
- Width 10mm
- Height 4.5mm
- Power consumption 11 W/m
- Current 458 mA/m
- Length 30m
- Cut intervals 50mm (cut marks are under the adhesive layer)
- IP rating IP66
- Beam angle 110°
- Working temperature -40°C to +55°C
- Voltage 24Vdc
In the Box
- 30m tape reel
